# Chapter 3 Hawkes process

A univariate Hawkes process is defined to be a self-exciting temporal point process where the conditional intensity function is given by

$\lambda(t) = \mu(t) + \Sigma_{i:\tau_i<t}\nu(t-\tau_i)$ where where $$\mu(t)$$ is the background rate of the process and $$\Sigma_{i:\tau_i<t}\nu(t-\tau_i)$$ is some historic temporal dependence. First introduced by Hawkes (1971), the classic homogeneous formulation is:

$\lambda(t) = \mu + \alpha \Sigma_{i:\tau_i<t}\text{exp}(-\beta * (t-\tau_i))$

## 3.1 The fit_hawkes() function

library(stelfi)
args(fit_hawkes)
## function (times, parameters = list(), model = 1, marks = c(rep(1,
##     length(times))), tmb_silent = TRUE, optim_silent = TRUE,
##     ...)
## NULL

### 3.1.1 Fitting a Hawkes model

A NIWA scientist found a working USB in the scat of a leopard seal, they then tweeted about it in the hopes of finding its owner.

data(retweets_niwa)
head(retweets_niwa)
## [1] "2019-02-07 06:50:08 UTC" "2019-02-07 06:50:08 UTC"
## [3] "2019-02-07 06:49:22 UTC" "2019-02-07 06:48:48 UTC"
## [5] "2019-02-07 06:47:52 UTC" "2019-02-07 06:47:42 UTC"
## numeric time stamps
times <- unique(sort(as.numeric(difftime(retweets_niwa ,min(retweets_niwa),units = "mins"))))
params <- c(mu = 9, alpha = 3, beta = 10)
fit <- fit_hawkes(times = times, parameters = params)
## print out estimated parameters
pars <- get_coefs(fit)
pars
##         Estimate  Std. Error
## mu    0.06328099 0.017783908
## alpha 0.07596531 0.007777899
## beta  0.07911346 0.008109789
show_hawkes(fit)

show_hawkes_GOF(fit)
##
##  Asymptotic one-sample Kolmogorov-Smirnov test
##
## data:  interarrivals
## D = 0.031122, p-value = 0.0001937
## alternative hypothesis: two-sided
##
##
##  Box-Ljung test
##
## data:  interarrivals
## X-squared = 3.3923, df = 1, p-value = 0.0655

### 3.1.2 Fitting an ETAS-type marked model

Here we fit a univariate marked Hawkes process where the conditional intensity function is given by

$\lambda(t; m(t)) = \mu + \alpha \Sigma_{i:\tau_i<t}m(\tau_i)\text{exp}(-\beta * (t-\tau_i))$ where $$\mu$$ is the background rate of the process and $$m(t)$$ is the temporal mark. Each event $$i$$ has an associated mark $$\tau_i$$ that multiples the self-exciting component of $$\lambda$$.

In this example, the events are earthquakes and the marks are the Richter magnitude of each earthquake.

data("nz_earthquakes")
head(nz_earthquakes)
## Simple feature collection with 6 features and 3 fields
## Geometry type: POINT
## Dimension:     XY
## Bounding box:  xmin: 172.3641 ymin: -43.63492 xmax: 172.7936 ymax: -43.42493
## CRS:           +proj=longlat +datum=WGS84 +no_defs +ellps=WGS84 +towgs84=0,0,0
##            origintime magnitude     depth                   geometry
## 1 2014-12-24 07:46:00  3.208996 13.671875 POINT (172.7133 -43.57944)
## 2 2014-12-24 06:43:00  4.109075  5.820312 POINT (172.7204 -43.55752)
## 3 2014-12-14 08:53:00  3.240377  5.058594 POINT (172.3641 -43.62563)
## 4 2014-12-12 13:37:00  4.459034  9.394531  POINT (172.368 -43.63492)
## 5 2014-11-20 08:24:00  3.116447 10.039062 POINT (172.7836 -43.42493)
## 6 2014-11-18 14:19:00  3.158710 11.269531  POINT (172.7936 -43.4897)
nz_earthquakes <- nz_earthquakes[order(nz_earthquakes$origintime),] nz_earthquakes <- nz_earthquakes[!duplicated(nz_earthquakes$origintime),]
times <- nz_earthquakes$origintime times <- as.numeric(difftime(times , min(times), units = "mins")) marks <- nz_earthquakes$magnitude
params <- c(mu = 3, alpha = 0.05, beta = 1)
fit <- fit_hawkes(times = times, parameters = params, marks = marks)
## print out estimated parameters
pars <- get_coefs(fit)
pars
##           Estimate   Std. Error
## mu    0.0002001766 1.206014e-05
## alpha 0.0005125373 2.934243e-05
## beta  0.0020558328 1.204552e-04
show_hawkes(fit)

show_hawkes_GOF(fit)
##
##  Asymptotic one-sample Kolmogorov-Smirnov test
##
## data:  interarrivals
## D = 0.035665, p-value = 0.0001912
## alternative hypothesis: two-sided
##
##
##  Box-Ljung test
##
## data:  interarrivals
## X-squared = 104.09, df = 1, p-value < 2.2e-16

## 3.2 The fit_mhawkes() function

args(fit_mhawkes)
## function (times, stream, parameters = list(), tmb_silent = TRUE,
##     optim_silent = TRUE, ...)
## NULL

A multivariate Hawkes process allows for between- and within-stream self-excitement. In stelfi the conditional intensity for the $$j^{th}$$ ($$j = 1, ..., N$$) stream is given by

$\lambda(t)^{j*} = \mu_j + \Sigma_{k = 1}^N\Sigma_{i:\tau_i<t} \alpha_{jk} e^{(-\beta_j * (t-\tau_i))},$ where $$j, k \in (1, ..., N)$$. Here, $$\alpha_{jk}$$ is the excitement caused by the $$k^{th}$$ stream on the $$j^{th}$$. Therefore, $$\boldsymbol{\alpha}$$ is an $$N \times N$$ matrix where the diagonals represent the within-stream excitement and the off-diagonals represent the excitement between streams.

data(multi_hawkes)
fit <- stelfi::fit_mhawkes(times = multi_hawkes$times, stream = multi_hawkes$stream,
parameters = list(mu =  c(0.2,0.2),
alpha =  matrix(c(0.5,0.1,0.1,0.5),byrow = TRUE,nrow = 2),
beta = c(0.7,0.7)))
get_coefs(fit)
##        Estimate Std. Error
## mu    0.2767272 0.10705381
## mu    0.1891731 0.08795223
## alpha 0.5116696 0.19277471
## alpha 0.1260672 0.10338890
## alpha 0.1311323 0.08845832
## alpha 0.6173171 0.21126133
## beta  0.9492155 0.35596511
## beta  0.8316319 0.29757181

## 3.3 The fit_hawkes_cbf() function

args(fit_hawkes_cbf)
## function (times, parameters = list(), model = 1, marks = c(rep(1,
##     length(times))), background, background_integral, background_parameters,
##     background_min, tmb_silent = TRUE, optim_silent = TRUE)
## NULL

### 3.3.1 Fitting an inhomogenous Hawkes process

Here we fit a univariate inhomogenous marked Hawkes process where the conditional intensity function is given by

$\lambda(t) = \mu(t) + \alpha \Sigma_{i:\tau_i<t}\text{exp}(-\beta * (t-\tau_i))$ The background $$\mu(t)$$ is time varying, rather than being constant.

The following example uses simulated data.

set.seed(1)
library(hawkesbow)
# Simulate a Hawkes process with mu = 1+sin(t), alpha=1, beta =2
times <- hawkesbow::hawkes(1000, fun=function(y) {1+0.5*sin(y)}, M=1.5, repr=0.5, family="exp", rate=2)$p We will attempt to recover these parameter values, modelling the background as$ (t) = A + Bsin(t)$. The background will be written as a function of $$x$$ and $$y$$, where $$A = e^x$$ and $$B= logit(y) e^x$$. This formulation ensures the background is never negative. ## The background function must take a single parameter and the time(s) at which it is evaluated background <- function(params,times){ A = exp(params[[1]]) B = stats::plogis(params[[2]]) * A return(A + B*sin(times)) } ## The background_integral function must take a single parameter and the time at which it is evaluated background_integral <- function(params,x){ A = exp(params[[1]]) B = stats::plogis(params[[2]]) * A return((A*x)-B*cos(x)) } param = list(alpha = 0.5, beta = 1.5) background_param = list(1,1) fit <- fit_hawkes_cbf(times = times, parameters = param, background = background, background_integral = background_integral, background_parameters = background_param) The estimated values of $$A$$ and $$B$$ respectively are exp(fit$background_parameters[1])
## [1] 1.025526
plogis(fit$background_parameters[2]) * exp(fit$background_parameters[1])
## [1] 0.5635566

The estimated values of $$\alpha$$ and $$\beta$$ respectively are:

ab <- get_coefs(fit)[1:2,1]
ab
##    alpha     beta
## 1.040863 2.179564

## 3.4 The sim_hawkes() function

args(sim_hawkes)
## function (mu, alpha, beta, n = 100, plot = FALSE, seed = 123,
##     method = "1")
## NULL

method = 1

sim <- sim_hawkes(mu = 2, alpha = 0.2, beta = 0.3, plot = TRUE)

head(sim)
## [1] 0.6231314 0.7420664 0.7986166 2.0856174 2.1293941 2.4093639

method = 2

sim <- sim_hawkes(mu = 2, alpha = 0.2, beta = 0.3, plot = TRUE, method = 2)

head(sim)
## [1] 0.6231314 0.7314123 1.1083232 1.1571593 1.1795519 2.2830958

### References

Hawkes, AG. 1971. “Spectra of Some Self-Exciting and Mutually Exciting Point Processes.” Biometrika.
